Home / Products / Isolators / Optoisolators - Logic Output / HCPL-6651

Broadcom Limited HCPL-6651

Name: HCPL-6651
Brand: Broadcom Limited
SKU: HCPL-6651
Price: 105.768 USD
Availability: InStock
Rating: 4.9 (689 reviews)

MFG Part Number: HCPL-6651

Available Quantity: 34000 Pieces

Reference Price: USD 105.768

Our Price: We have a big discount, please contact us

Shipping Date: We can ship out today

Manufacturer: Broadcom Limited

Brief Description: - OPTOISO 1.5KV OPEN COLL 16FLATPK

Lead Free Status / RoHS Status: RoHS Compliant (Lead Free)

Moisture Sensitivity Level (MSL): 1 (Unlimited)

Date Code (D/C): New

Product Category: Optoisolators - Logic Output

Stock Resource: Franchised Distributor

Warranty: 360 days quality guarantee

Datasheet: HCPL-6651.pdf

Request Quotation for HCPL-6651

Company Name

Contact Person

Phone Number

Address

Email

Message

HCPL-6651 Specifications

Manufacturer Part Number	HCPL-6651
Future Part Number	FT-HCPL-6651
SPQ / MOQ	Contact Us
Packing Material	Reel/Tray/Tube/Others
Series	-
HCPL-6651 Status (Lifecycle)	In Stock
Part Status	Active
Number of Channels	4
Inputs - Side 1/Side 2	4/0
Voltage - Isolation	1500VDC
Common Mode Transient Immunity (Min)	1kV/µs
Input Type	DC
Output Type	Open Collector, Schottky Clamped
Current - Output / Channel	25mA
Data Rate	10MBd
Propagation Delay tpLH / tpHL (Max)	100ns, 100ns
Rise / Fall Time (Typ)	35ns, 35ns
Voltage - Forward (Vf) (Typ)	1.5V
Current - DC Forward (If) (Max)	20mA
Voltage - Supply	4.5V ~ 5.5V
Operating Temperature	-55°C ~ 125°C
Mounting Type	Surface Mount
Package / Case	16-Flatpack
Supplier Device Package	16-Flatpack
Country of Origin	USA/JAPAN/MALAYSIA/MEXICO/CN
HCPL-6651 Weight	Contact Us
Replacement Part Number	HCPL-6651-FT
